The Area Light Series LumeX1 and LumeX2 comes in a small size with a lumen output between 9,000 to 13,400 lumens. This versatile luminaire has different mounting options, photocell, and motion sensors for efficiency and greater energy savings.
APPLICATIONS
Auto Dealerships, Parking Lots, Walkways, Roadways, and other
Public Areas, etc.
REPLACEMENT
ALS:175W- 250W MH
| Product Series | Performance | Wattage | 70W , 105W |
| Lumen Output | 9000 LM , 13400 LM | Correlated Color Temperature (CCT) | 4000K , 5000K |
| Product Distribution Types | T3, T4, T5 | Control | Dimmable Motion Sensor |
| Accessories | Twist-lock Photocell , House Side Shield | Mounting Type | Square and Round Pole , Wall Mount , Slipfitter Mount , Trunnion Mount , Yoke Mount |
| Environment | Outdoor | Shape | Rectangle |
| Listings | UL , FCC | Product Type | Area Light |
| Generation | G2 | Color & Finish | Dark Bronze Polyester Powder |
| Light Source | LED – Static | Voltage Rating | Standard 120-277V, HVU 347-480V |
| Warranty | 10 Year | Labor Warranty | Yes |
| Part Number | Description |
|---|---|
| PC- 2 NEMA Twist-lock Photocell 377V-480V |  |
| PC- 1 NEMA Twist-lock Photocell 120V-277V |  |
| PC- 3 7-Pin NEMA Twist-lock Receptacle |  |
| MS-FSP-212 Dimmable Motion Sensor |  |
| MS-FSP-221B Dimmable Motion Sensor |  |
| Square and Round Pole Mount |  |
| Wall Mount |  |
| SPS Pole Accessories |  |
| SS450-02 On-Site Wireless Controller |  |
| SSSK |  |
| Product Series | Performance | Wattage | 70W , 105W |
| Lumen Output | 9000 LM , 13400 LM | Correlated Color Temperature (CCT) | 4000K , 5000K |
| Product Distribution Types | T3, T4, T5 | Control | Dimmable Motion Sensor |
| Accessories | Twist-lock Photocell , House Side Shield | Mounting Type | Square and Round Pole , Wall Mount , Slipfitter Mount , Trunnion Mount , Yoke Mount |
| Environment | Outdoor | Shape | Rectangle |
| Listings | UL , FCC | Product Type | Area Light |
| Generation | G2 | Color & Finish | Dark Bronze Polyester Powder |
| Light Source | LED – Static | Voltage Rating | Standard 120-277V, HVU 347-480V |
| Warranty | 10 Year | Labor Warranty | Yes |
| Part Number | Description |
|---|---|
| PC- 2 NEMA Twist-lock Photocell 377V-480V |  |
| PC- 1 NEMA Twist-lock Photocell 120V-277V |  |
| PC- 3 7-Pin NEMA Twist-lock Receptacle |  |
| MS-FSP-212 Dimmable Motion Sensor |  |
| MS-FSP-221B Dimmable Motion Sensor |  |
| Square and Round Pole Mount |  |
| Wall Mount |  |
| SPS Pole Accessories |  |
| SS450-02 On-Site Wireless Controller |  |
| SSSK |  |
LEDs can be programmed to create dynamic lighting effects that enhance the game-day experience for everyone involved and can provide superior lighting for playing fields and arenas, improving visibility for athletes and spectators alike.
One of the biggest benefits of commercial LED lighting is the decrease in energy costs. Traditional incandescent and metal-halide lights can use up to four times as much energy as commercial LED lights. This decrease in energy consumption not only saves money, but also helps reduce your facility’s carbon footprint.
Commercial LED lights also last much longer than traditional lighting options. While incandescent bulbs typically only last around 1,000 hours, commercial LED lights can last up to 100,000 hours. This not only reduces maintenance and replacement costs, but also reduces the amount of time your facility needs to be dark while lights are being replaced.
Another key benefit of commercial LED lighting is increased safety. Because commercial LED lights produce ve ry little heat, there is less risk of fire hazards. Additionally, commercial LED lights can be designed with specific light patterns that can help improve visibility for athletes and spectators alike. This improved visibility can help prevent accidents and injuries on the playing field or in the stands.
